HIDRAULINIS PRESAS WK-8, RINKINYS
Elmark
428,17 €
Su mokesčiais
Pristatymas per 7-14 dienas
Technical characteristics:
- Piercing head turning at 360°
- Shape of the cutting element: Round
- Size of the cutting element: Ø22, 27.5, 34.3, 40, 49, 60.8mm
- Piercing capacity
= Metal sheet 3mm: openings up to Ø30mm
= Metal sheet 2mm: openings up to Ø60mm
- Element pressing strength: 80kN
-...
Technical characteristics:
- Piercing head turning at 360°
- Shape of the cutting element: Round
- Size of the cutting element: Ø22, 27.5, 34.3, 40, 49, 60.8mm
- Piercing capacity
= Metal sheet 3mm: openings up to Ø30mm
= Metal sheet 2mm: openings up to Ø60mm
- Element pressing strength: 80kN
- Thickness of th element: 25mm
\n
Functions:
- Cutting through openings in metal sheet with gauge up to 3mm without rotary motion
\n
Advantages:
- Metal box for the instrument
- A set of congestion hoops for the hydraulic cylinder
- Additional set of cutting elements for cable glands – Ø16, 20, 26.2, 32.5, 39, 51, 63
and a square for display devices 46.5x46.5, 68x68 (ordered additionally as Cat.number: 54002)
\n
Duomenų lapas
- Prekinis ženklas
- ELMARK
- Kategorija
- I4
- Gaminio neto svoris kg
- 6.950
- Bruto svoris kg
- 7.350
- Garantija
- 2+0
- Neto svoris kg
- 6.950
- Svoris
- 7.350
