VALDYMO ĮTAMPOS TRANSFORMATORIUS EVT5-500VA 400V/48V-24V-12V

VALDYMO ĮTAMPOS TRANSFORMATORIUS EVT5-500VA 400V/48V-24V-12V

Elmark
88,52 € Su mokesčiais
Technical characteristics: - Input voltage: 400 or 230V - Frequency: 50/60Hz - Short circuit resistance: unstable - Temperature class: B (130°Ð¡) - Construction: open (for installation in other products) - Magnetic circuit: cold rolled electric furnace steel - Coils: pure electrotechnical copper -...
Nuoroda
3800131123244
Išparduota
Perskaitykite apžvalgas (0)

Technical characteristics:
- Input voltage: 400 or 230V
- Frequency: 50/60Hz
- Short circuit resistance: unstable
- Temperature class: B (130°Ð¡)
- Construction: open (for installation in other products)
- Magnetic circuit: cold rolled electric furnace steel
- Coils: pure electrotechnical copper
- IP code: IP20
- Ambient temperature: -20° to 65°Ð¡

\n


Mounting:
- In distribution boards or products
- Vertically on the surface using bolts

\n

Standard: EN60051-1

Duomenų lapas

Prekinis ženklas
ELMARK
Kategorija
E1
Bendra galia W
Gaminio neto svoris kg
5.950
Bruto svoris kg
0.000
Bruto svoris kg
6.100
Garantija
3+0
Neto svoris kg
5.950
Galia
500VA
Svoris
6.100
