Liekamosios srovės relė JEL1 4P 16A/500MA
62,29 € Su mokesčiais
\n
Technical characteristics:
- Rated current: 10-100 Ð
- Rated operating voltage: 230/400V; 50/60Hz
- Rated residual current: 30/100/300/500 mA
- Number of poles: 2/4
- Surge voltage wear resistance: ≥2000V
- Short circuit current wear resistance: 6000Ð
- IP code: IP>20
- Ambient temperature: -10°÷65ºÐ¡
- Installation altitude: up to 2000m
Mounting: Vertical on a DIN rail
\nStandards: EN 61008-1; EN 61008-2; EN 60947-1
Duomenų lapas
- Brand
- ELMARK
- Category
- Dimension
- L:72/W:70/H:81
- Product net weight kg
- 0.250
- Weight Gross kg
- 0.290
- Warranty
- 7+0
- Weight Net kg
- 0.250
- Dimensions (mm)
- L:72/W:70/H:81
- Svoris
- 0.290
