PLASTMASAS KASTE VIRSMAS UZSTĀDĪŠANAI 4 VIRZIENU

Technical characteristics:
- Maximum insulation voltage: 690V,50Hz
- Number of modules: 4/6/8/12/18/24/36
- Fire resistance rate: UL 94
- IP code: IP40
- Class of current limiting: 2

Advantages:
- They are made of white self-extinguishing plastic, resistant to fire and high temperatures with IP40
- The mounted in the box device is protected from direct contact with current conductive parts
- Offered with DIN rail for device mounting and terminal blocks for joining of the neutral and the grounding conductor

Applications:
- Newly built buildings or buildings in reconstruction

Mounting: Surface mounting

Standards: EN62208; EN60439-1; EN60439-3
