55,80 €
Pooljuhtrelee ZG3NC-3-20B 400VAC 20A 2P
Elmark
30,47 €
Maksudega
Tarne 7-14 päeva
Technical characteristics:
- Load/output voltage: 30/400V, 50Hz
- Rated current: from 10Ð to 60Ð
- Insulating voltage: 1000 MΩ / min (500V)
- Surge voltage wear resistance: 2000V, 50Hz
- Dielectric strength: <2500VAC / 1 min
- Leakage current: <2 mA
- Switch ON time: <10ms
- Operating...
Technical characteristics:
- Load/output voltage: 30/400V, 50Hz
- Rated current: from 10Ð to 60Ð
- Insulating voltage: 1000 MΩ / min (500V)
- Surge voltage wear resistance: 2000V, 50Hz
- Dielectric strength: <2500VAC / 1 min
- Leakage current: <2 mA
- Switch ON time: <10ms
- Operating temperature: -5°Ð¡ - + 65°Ð¡
- Relative humidity: 35 - 85% RH
Andmeleht
- Bränd
- ELMARK
- Kategooria
- E1
- Toote netokaal kg
- 0.086
- Brutokaal kg
- 0.090
- Garantii
- 3+2
- Netokaal kg
- 0.086
- Kaal
- 0.090
