KONDENSAATORAKUD HY-11B25 25kVAr 690V

Technical characteristics:
- Capacity range: 5-30kVAr
- Operating voltage: 450V;50Hz
- Insulation voltage: 690V
- Operating temperature: -40° to 65°C
- Capacity tolerance: ±5%
- Rated frequency: 50-60HZ
- Level of discharge (per minute): <50V
- Maximum altitude: 2000m

\n

Advantages:
- Used for correction of the power factor
- Compensation of reactive energy
- Reliable work
- High overload resistance
- Long life

\n

Functions:
- Systems with high levels of harmonic distortion
- Compensation of the reactive energy

Applications:
- Public buildings
- Industry
- Wind turbines (HY-111B12; HY-11B25)

\n

Mounting: Using bolts with sizes M12 or Ðœ16 to a flat horizontal surface

\n

Standards: EN60831-1; EN60831-2
