Miniatuurne kaitselüliti C42N/6A 2P, kõver C

Miniatuurne kaitselüliti C42N/6A 2P, kõver C

Elmark
0,00 € Maksudega
Tarne 7-14 päeva
Technical characteristics: - Rated operating voltage: 230/400V; 50/60Hz - Rated current: 2-63А - Breaking capacity: 4500А - Poles: 1, 2, 3 - Tripping curve: C С - the maximum current release breaks between 5 and 10 In;used to protect main power supply cables and conventional consumers \n -...
Viide
41470C
Saadav (113 Tooted)
Loe arvustusi (0)

Technical characteristics:
- Rated operating voltage: 230/400V; 50/60Hz
- Rated current: 2-63А
- Breaking capacity: 4500А
- Poles: 1, 2, 3
- Tripping curve: C
С - the maximum current release breaks between 5 and 10 In;used to protect main power supply cables and conventional consumers

\n

- Electrical wear resistance (number of cycles ):≥4000
- Mechanical wear resistance (number of cycles):≥20000
- Limitation class: 3
- IP code: IP>20
- Ambient temperature: -5 to +65°Ð¡±2°Ð¡

\n


Mounting: Vertical on a DIN rail

\n

Standards: EN60898-1

Andmeleht

Bränd
ELMARK
Bränd
elmark
Kategooria
E1
Mõõde
L:72/W:36/H:78
Toote netokaal kg
0.055
Brutokaal kg
0.060
Brutokaal kg
0.204
Garantii
7+0
Garantii
7+0(I3)
Netokaal kg
0.055
Mõõtmed (mm)
L:72/W:36/H:78
Kaal
0.060
Tüüp
E1
