ROTARY SWITCH LW26-160S 160A , 4 LEVELS , 3 POSITIONS

ROTARY SWITCH LW26-160S 160A , 4 LEVELS , 3 POSITIONS

Name: ROTARY SWITCH LW26-160S 160A , 4 LEVELS , 3 POSITIONS
Brand: Elmark
SKU: 3800131121110
Price: 417.65 EUR
Availability: InStock

€417.65 Tax included

Reference

3800131121110

Available (403 Items)

Read reviews (0)

Free shipping

In Estonia from 75 € of purchases

Secure payment

100% secure online payment

Easy returns

Returns possible for 14 days

Customer service

24/7 WhatsApp

Description

Technical characteristics:
- Power supply voltage: 230/400V, 50Hz
- Number of levels: 4
- Number of positions: 3
- Insulation voltage: 690V
- Impulse voltage withstand: 6000V
- Mechanical wear resistance: 3Ñ…105 commutation cycles
- Operating temperature: -10°Ð¡ - +50°Ð¡
- Humidity: 35 - 85%RH
- Commutation capacity: 25-160Ð
- Resistant to UV rays plastic
- Cable connection: screw joining
- Tightening torque of the bolt: 1.33Nm
- Maximum section of the power supply conductors: 16.0mm2

Mounting:
- Directly to the control panel
- Thickness of the surface: max 5mm

Standards: EN 60947-1; EN 60947-3-1

Data sheet
