Трансформатор управляющего напряжения EVT5-1600VA 400V/48V-24V-12V
238,39 € С НДС
Technical characteristics:
- Input voltage: 400 or 230V
- Frequency: 50/60Hz
- Short circuit resistance: unstable
- Temperature class: B (130°Ð¡)
- Construction: open (for installation in other products)
- Magnetic circuit: cold rolled electric furnace steel
- Coils: pure electrotechnical copper
- IP code: IP20
- Ambient temperature: -20° to 65°Ð¡
Mounting:
- In distribution boards or products
- Vertically on the surface using bolts
Standard: EN60051-1
Data sheet
- Brand
- ELMARK
- Category
- E1
- Total power W
- Product net weight kg
- 14.300
- Weight Gross kg
- 14.500
- Warranty
- 3+0
- Weight Net kg
- 14.300
- Power
- 1600VA
- Вес
- 14.500
