DOUBLE CONNECTOR TYPE MC4 4-6ММ² 2 MALE/1 FEMALE

Double male/single female cable coupler is compatible with MC4 connectors and is suitable with solar power cable H1Z2Z2-K with cross section 2.5mm2; 4mm2 and 6mm2. Quickly and reliable connection of the solar cables to the

photovoltaic panels.

TECHNICAL DATA:

• Rated voltage: 1000V

• Rated current: 30A

• Test voltage: 6KV(50Hz)

• IP code: IP67

• Contact material: Copper, sliver plated

• Operating temperature: -40 to +125°C

• Suitable cable cross section: 2.5mm2; 4mm2 and 6mm2

• Range of cable glands: 3-6mm
