RESIDUAL CURRENT DEVICE JEL1A 2P 63A/100MA

JÄÄNNÖSVIRTAKATKA JEL1A 2P 63A/100MA

35,12 € Sisältää alv:n
Viite
3800131138460
Käytettävissä oleva (99 Tuotteet)



\n

Technical characteristics:
- Rated current: 10-100 А
- Rated operating voltage: 230/400V; 50/60Hz
- Rated residual current: 30/100/300/500 mA
- Number of poles: 2/4
- Surge voltage wear resistance: ≥2000V
- Short circuit current wear resistance: 6000А
- IP code: IP>20
- Ambient temperature: -10°÷65ºÐ¡
- Installation altitude: up to 2000m

\n

Mounting: Vertical on a DIN rail

\n

Standards: EN 61008-1; EN 61008-2; EN 60947-1

Tietolomake

Brand
ELMARK
Category
E1
Dimension
L:72/W:35/H:81
Product net weight kg
0.211
Weight Gross kg
0.229
Warranty
7+0
Weight Net kg
0.211
Dimensions (mm)
L:72/W:35/H:81
Paino
0.229
